[kInOzAwA]

here's my 2009 custom watercooling rig, using it up till nowadays...

rig's spec:
Intel Core i7 920 D0 (o'Ced to min 4.2ghz - max 4.6ghz)
DFI X58 - T3eH6 LGA1366 Motherboard
Corsair Dominator 3X2GB 1600Mhz CL8 DDR3 RAM (7-8-7-20 @ 1.65v)
Sapphire Radeon HD3870 X2 (Crossfire-X) {rarely gaming, so don't need high end GC yet. i assume i'm one of the enthusiast. lol. }
Creative SoundBlaster X-Fi Elite Pro Soundcard
LG Flatron W2253TQ [1920X1080 resolution]
Logitech G15 V2 Keyboard
Roccat Kone V2 Mouse
CoolerMaster RealPower 1000W Modular PSU
CoolerMaster Cosmos S High-Tower Case
Klipsch ProMedia GMX 2.1 Multimedia Speaker (old one but still kicks-ass!)

Custom Watercooling Specs:
Swiftech Apogee XT LGA1366 CPU Waterblock
Swiftech MCW60-R Ver. 2 GPU Waterblock [universal]
TFC X-Changer 360 Triple Radiator
TFC X-Changer 240 Dual Radiator
Tygon R-3603 7/16" Tubing
Swiftech MCP655 D5-Vario Waterpump [EK D5 X-Top G1/4 Rev. 2 Pump Top]
EK-MultiOption Reservoir 250
Bitspower G1/4 Rotary Adapters (45 & 90 degrees)
Bitspower 7/16"ID Compression Fittings
Danger Den 1/2"ID Fat Boy Barb
Yate Loon D12SM-12 Fans
Scythe S-Flex SFF21G Fans



[linnemeyerhere]

kInOzAwA, The Rig is handsome ! I love the way the parts glow. Getting this to almost 4.7ghz is amazing if not the most stable. Great job as I'm sure it runs like a scalded ape !



[Dave76]

Very nice clean looking rig, congrats.

What's the Prime95 temps on that water cooled 4.6GHz OC?



[Beginning]

kInOzAwA - That is one beautiful rig you got there... Thanks for sharing!



[tw33k]

@kInOzAwA...very nice



[Lordbob75]

I am going to borrow my roommates (nice) camera today and get some good pictures of my rig to post up here.

Kinozawa, nice looking rig there. How do you have your loop setup?

~Lordbob



[linnemeyerhere]

Lordbob75,
It appears to be CPU to triple core cooler to GPU's to 2nd cooler to reservoir to pump back to CPU.



[ZaLiTH]

Lordbob75,
It appears to be CPU to triple core cooler to GPU's to 2nd cooler to reservoir to pump back to CPU.

Excuse my ignorance, but I've never really had any experience with water cooling setups... Does that mean the liquid gets cooled just before the CPU and then again just before the GPUs?

That's actually a really awesome way to set it up..



[Lordbob75]

Lordbob75,
It appears to be CPU to triple core cooler to GPU's to 2nd cooler to reservoir to pump back to CPU.

Excuse my ignorance, but I've never really had any experience with water cooling setups... Does that mean the liquid gets cooled just before the CPU and then again just before the GPUs?

That's actually a really awesome way to set it up..

Actually, the water absorbs the heat from the CPU and then looses it in the radiator, then goes back to the pump then CPU.

~Lordbob



[ZaLiTH]

Lordbob75,
It appears to be CPU to triple core cooler to GPU's to 2nd cooler to reservoir to pump back to CPU.

Excuse my ignorance, but I've never really had any experience with water cooling setups... Does that mean the liquid gets cooled just before the CPU and then again just before the GPUs?

That's actually a really awesome way to set it up..

Actually, the water absorbs the heat from the CPU and then looses it in the radiator, then goes back to the pump then CPU.

~Lordbob

Yeah, I do understand the way water cooling systems work with heat transfer, but with that specific setup (two radiators or 'coolers'), that essentially means the heat from the CPU is absorbed by one radiator before the liquid reaches the GPUs, and heat from the GPUs is absorbed by the other radiator before the liquid reaches the CPU. Or am I mistaken there...?

I've never used a water cooling setup myself, but I've read a lot about them online. Just never really thought of using more than one radiator in the same loop... I have seen setups with two completely independent loops though.



[crazyeyeschase]

Radiators are full of small chambers which dramatically increase the amount of surface area then water can be cooled.

Air flows thru the fins which hold water the flowing air picks up the heat from the fins and blows it away causing the fluid leaving the radiator to e much cooler then it was when it entered.

Now water boils at 212F about 93c and freezes at 32F and 0c now I'm not 100% on computer coolant but car coolant has an alcohol based product (there's 3 types) which increases the boil point and decreases the freezing point. Cars run at about 200F just about the boiling point of water that’s why they need antifreeze and since many places like where I live gets below 32 very often you need antifreeze to be able to start the car or else many major parts would freeze and lock up.

Now I'm surprised we don't have any sort of Freon cooling going on I'm going to research that.

Still surprises me how big the coolant tubes in a PC are.



[crazyeyeschase]

Excuse my ignorance, but I've never really had any experience with water cooling setups... Does that mean the liquid gets cooled just before the CPU and then again just before the GPUs?

That's actually a really awesome way to set it up..

Actually, the water absorbs the heat from the CPU and then looses it in the radiator, then goes back to the pump then CPU.

~Lordbob

Yeah, I do understand the way water cooling systems work with heat transfer, but with that specific setup (two radiators or 'coolers'), that essentially means the heat from the CPU is absorbed by one radiator before the liquid reaches the GPUs, and heat from the GPUs is absorbed by the other radiator before the liquid reaches the CPU. Or am I mistaken there...?

I've never used a water cooling setup myself, but I've read a lot about them online. Just never really thought of using more than one radiator in the same loop... I have seen setups with two completely independent loops though.

You are very right.

The only problem I see would be extra strain on the pump but that shouldn’t be that big of a deal.

If I ever get to building a water cooled system I'm pulling all the stops and will use some sort of thermostat haven't really looked into water cooling yet.



[ZaLiTH]

The only problem I see would be extra strain on the pump but that shouldn’t be that big of a deal.

If I ever get to building a water cooled system I'm pulling all the stops and will use some sort of thermostat haven't really looked into water cooling yet.

I'd guess that with a decent pump that shouldn't cause any problems though... My next build will be water cooled, but that's an adventure for later on when RAF pay out for the bike accident I had a few years back. When that happens I'm planning to drop about R30k to R35k (about $4500 to $5000 USD at the current exchange rate) on a completely new system... So when I get closer to the time I'll start doing more in-depth research first.

I really like the thermostat idea though, that would definitely be a nice way to see if the cooling setup is good enough for the hardware it's cooling....
