front usb not usb 2.0 help

[sinbin]

My 4 front usb are only working at 1.1 speed,as every time i connect my mp3 player it says this device can perform faster if connect to a usb port in bold!
I have usb 2.0 on my mobo and it shows i have the port.
My gaming cas says 4 front usb 2.0 ports aswell

I wired them to the usb 1 and usb 2 pins on the mobo.

I cannot find why this is ,the back usb work fine in usb 2.0

ANy help to this problem please!!!

If you need info my specs are below!!!



[sinbin]

I also contacted gigabyte the mobo maker and they said they should be working in usb 2.0!



[theog]

Is the cable you are using USB 1?



[pbcopter]

Is this something that just happened?

Have you installed SP1 for Windows 7?



[sinbin]

It allways been usb on front,im using cables that come from the new case usb !!



[sinbin]

Is the cable you are using USB 1?

The case says front usb 2.0 x 4.cables came with the case



[theog]

Are any cable's from front USB's to Device's, USB 1?



[sinbin]

Are any cable's from front USB's to Device's, USB 1?

do you mean the grey cables that come from the front usb,,and how do i tell the difference?



[theog]

The cable will be marked, HI-SPEED USB Revision 2.0 for USB2, NO marking for USB1.



[sinbin]

the cables are plain grey?but the case specs say 4 x front usb 2.0 sklots ?



[Devux]

Even if the port is USB2.0 and the device is 2.0 if you use a USB 1.1 cable, it is going to operate at that speed.



[Sardonicus]

Hello,
Please correct your specs, the mobo info you give, I don't think is incorrect.
In your BIOS, you have the "On-Chip USB" option, set it to the default setting.



[sinbin]

Hello,
Please correct your specs, the mobo info you give, I don't think is incorrect.
In your BIOS, you have the "On-Chip USB" option, set it to the default setting.

View attachment 144774

View attachment 144775[/QUO
I got another mobo question if you can find the time to digest it!
My side fan has a 3 pin connector.i have a sys header 4 pin slot on my mobo free,will this control the fan speed to temperature of system or cpu.
Also how do i connect 3 pin to 4 pin!i can give pics if needed



[Sardonicus]

Hello,
Please correct your specs, the mobo info you give, I don't think is incorrect.
In your BIOS, you have the "On-Chip USB" option, set it to the default setting.

View attachment 144774

View attachment 144775

Ive seen this optin in my bios,,what do i do to each setting in the pic ?
I use tons of usb gadjets and really would like to use the 4 front usb at 2.0 speed thanks for any help!

Oh thanks for heads up on mobo info,,changed it have no idea why i typed that

Sorry, I didn't make it clear.
There are 3 options.
Of the three options, use "V1.1+V2.0 Enables the integrated USB 1.1 and USB 2.0 controllers. (Default}"

You probably have it set to "V1.1 Enables only the integrated USB 1.1 controller"



[Sardonicus]

Hello,
Please correct your specs, the mobo info you give, I don't think is incorrect.
In your BIOS, you have the "On-Chip USB" option, set it to the default setting.

View attachment 144774

View attachment 144775[/QUO
I got another mobo question if you can find the time to digest it!
My side fan has a 3 pin connector.i have a sys header 4 pin slot on my mobo free,will this control the fan speed to temperature of system or cpu.
Also how do i connect 3 pin to 4 pin!i can give pics if needed

According to the manual, yes.
There system fan has a notch for a 3 pin fan. Just plug it in.
Be sure to enable "System Smart FAN Control" in the BIOS.



[sinbin]

Turns out i been using a usb 1.0 lead,never knew i owned one.
Had a look at my leads and found one with high speed written on cable now everything works fine.



[theog]

Turns out i been using a usb 1.0 lead,never knew i owned one.
Had a look at my leads and found one with high speed written on cable now everything works fine.

You are welcome.



[sinbin]

Is the cable you are using USB 1?

Thanks i should of checked this first ,but did,nt think i owned a usb 1 lead!
